Complete forearm plate set. Radius plates: volar and dorsolateral configurations. Ulna plates: diaphyseal and shortening configurations. Manufactured from titanium alloy, with dynamic compression and locking holes that allow interfragmentary compression and stable angular fixation.
Diaphyseal fractures of the radius.
Diaphyseal fractures of the ulna.
Fractures of both forearm bones.
Corrective osteotomies of the radius and/or ulna.
Diaphyseal nonunions of the forearm.
Straight and anatomically precontoured models.
Combined holes: for locking and 3.5 mm cortical screws.
Low profile that reduces soft tissue irritation.
Different lengths (6 to 12 holes, depending on bone and location).
Speak with our specialists, receive personalized assistance, and optimize your experience in the operating room with a solution designed for precision and confidence.
| Forearm fracture plate and screw set / 0AB-02-0000-T-O | |||
|---|---|---|---|
| IMPLANTS | |||
| SYSTEM CODE | 0AB-02-0000-T-O | ||
| SYSTEM DESCRIPTION | FOREARM SYSTEM | ||
| REF. | DESCRIPTION | LENGTH (mm) / HOLES | QTY |
| 2788-006 | LOCKING PLATE FOR DIAPHYSEAL ULNA 3.5 MM 6 HOLES TITANIUM | 79 / 6 | 1 |
| 2788-008 | LOCKING PLATE FOR DIAPHYSEAL ULNA 3.5 MM 8 HOLES TITANIUM | 111 / 8 | 1 |
| 2788-010 | LOCKING PLATE FOR DIAPHYSEAL ULNA 3.5 MM 10 HOLES TITANIUM | 135 / 10 | 1 |
| 2788-012 | LOCKING PLATE FOR DIAPHYSEAL ULNA 3.5 MM 12 HOLES TITANIUM | 167 / 12 | 1 |
| 2789-006 | DORSOLATERAL LOCKING PLATE FOR DIAPHYSEAL RADIUS 3.5 MM 6 HOLES TITANIUM | 79 / 6 | 1 |
| 2789-008 | DORSOLATERAL LOCKING PLATE FOR DIAPHYSEAL RADIUS 3.5 MM 8 HOLES TITANIUM | 111 / 8 | 1 |
| 2789-010 | DORSOLATERAL LOCKING PLATE FOR DIAPHYSEAL RADIUS 3.5 MM 10 HOLES TITANIUM | 135 / 10 | 1 |
| 2789-012 | DORSOLATERAL LOCKING PLATE FOR DIAPHYSEAL RADIUS 3.5 MM 12 HOLES TITANIUM | 167 / 12 | 1 |
| 2790-006 | VOLAR LOCKING PLATE FOR DIAPHYSEAL RADIUS 3.5 MM 6 HOLES TITANIUM | 79 / 6 | 1 |
| 2790-008 | VOLAR LOCKING PLATE FOR DIAPHYSEAL RADIUS 3.5 MM 8 HOLES TITANIUM | 111 / 8 | 1 |
| 2790-010 | VOLAR LOCKING PLATE FOR DIAPHYSEAL RADIUS 3.5 MM 10 HOLES TITANIUM | 135 / 10 | 1 |
| 2790-012 | VOLAR LOCKING PLATE FOR DIAPHYSEAL RADIUS 3.5 MM 12 HOLES TITANIUM | 167 / 12 | 1 |
| 2837-000 | LOCKING ULNA REDUCTION PLATE ULNIQUE, TITANIUM | 87 / 7 | 1 |
| SYSTEM CODE | 0AB-02-0000-T-O | ||
| SYSTEM DESCRIPTION | FOREARM SYSTEM | ||
| REF. | DESCRIPTION | LENGTH (mm) | QTY |
| 0987-010 | CORTICAL SCREW S2 3.5 MM X 10 MM TITANIUM | 10 | 4 |
| 0987-012 | CORTICAL SCREW S2 3.5 MM X 12 MM TITANIUM | 12 | 4 |
| 0987-014 | CORTICAL SCREW S2 3.5 MM X 14 MM TITANIUM | 14 | 4 |
| 0987-016 | CORTICAL SCREW S2 3.5 MM X 16 MM TITANIUM | 16 | 8 |
| 0987-018 | CORTICAL SCREW S2 3.5 MM X 18 MM TITANIUM | 18 | 8 |
| 0987-020 | CORTICAL SCREW S2 3.5 MM X 20 MM TITANIUM | 20 | 8 |
| 0987-022 | CORTICAL SCREW S2 3.5 MM X 22 MM TITANIUM | 22 | 8 |
| 0987-024 | CORTICAL SCREW S2 3.5 MM X 24 MM TITANIUM | 24 | 4 |
| 0987-026 | CORTICAL SCREW S2 3.5 MM X 26 MM TITANIUM | 26 | 4 |
| 0987-028 | CORTICAL SCREW S2 3.5 MM X 28 MM TITANIUM | 28 | 4 |
| 0987-030 | CORTICAL SCREW S2 3.5 MM X 30 MM TITANIUM | 30 | 4 |
| 0987-035 | CORTICAL SCREW S2 3.5 MM X 35 MM TITANIUM | 35 | 2 |
| 0987-040 | CORTICAL SCREW S2 3.5 MM X 40 MM TITANIUM | 40 | 2 |
| 0988-010 | LOCKING CORTICAL SCREW S2 3.5 MM X 10 MM TITANIUM | 10 | 6 |
| 0988-012 | LOCKING CORTICAL SCREW S2 3.5 MM X 12 MM TITANIUM | 12 | 6 |
| 0988-014 | LOCKING CORTICAL SCREW S2 3.5 MM X 14 MM TITANIUM | 14 | 18 |
| 0988-016 | LOCKING CORTICAL SCREW S2 3.5 MM X 16 MM TITANIUM | 16 | 18 |
| 0988-018 | LOCKING CORTICAL SCREW S2 3.5 MM X 18 MM TITANIUM | 18 | 18 |
| 0988-020 | LOCKING CORTICAL SCREW S2 3.5 MM X 20 MM TITANIUM | 20 | 18 |
| 0988-022 | LOCKING CORTICAL SCREW S2 3.5 MM X 22 MM TITANIUM | 22 | 9 |
| 0988-024 | LOCKING CORTICAL SCREW S2 3.5 MM X 24 MM TITANIUM | 24 | 6 |
| 0988-026 | LOCKING CORTICAL SCREW S2 3.5 MM X 26 MM TITANIUM | 26 | 6 |
| 0988-028 | LOCKING CORTICAL SCREW S2 3.5 MM X 28 MM TITANIUM | 28 | 6 |
| 0988-030 | LOCKING CORTICAL SCREW S2 3.5 MM X 30 MM TITANIUM | 30 | 6 |
| 0988-035 | LOCKING CORTICAL SCREW S2 3.5 MM X 35 MM TITANIUM | 35 | 2 |
| 0988-040 | LOCKING CORTICAL SCREW S2 3.5 MM X 40 MM TITANIUM | 40 | 2 |
| ASSOCIATED INSTRUMENTS | |||
| SYSTEM CODE | 0AB-02-0000-T-O | ||
| SYSTEM DESCRIPTION | FOREARM SYSTEM | ||
| REF. | DESCRIPTION | QTY | |
| 6139-020 | LINEAR QUICK-CHANGE HANDLE | 2 | |
| 5333-000 | QUICK COUPLING T15 SCREWDRIVER X 95.0 MM | 2 | |
| 5708-000 | QUICK COUPLING TAP FOR CORTICAL BONE 3.5 MM P1,25 | 1 | |
| 5925-000 | SMALL HOFFMAN LEVER FOR SMALL FRAGMENTS | 1 | |
| 5926-000 | LARGE HOFFMAN LEVER FOR SMALL FRAGMENTS | 1 | |
| 5617-020 | CURETTE 3.5 MM | 1 | |
| 5914-000 | PLATE BENDING IRON 3.5 #1 | 2 | |
| 5803-000 | SCREW FORCEPS #1 | 1 | |
| 5802-000 | LOBSTER CLAW FORCEPS 3.5 MM | 1 | |
| 5808-000 | REDUCTION FORCEPS 3.5 MM | 1 | |
| 5204-000 | SIZING BLOCK FOR SCREWS, 3.5 MM | 1 | |
| 6402-000 | LOCKING DRILL BIT GUIDE 3.5 X 50 MM | 1 | |
| 6403-000 | LOCKING DRILL BIT GUIDE 3.5 X 70 MM | 1 | |
| 6485-000 | COMBINED DRILL BIT GUIDE 2.5 / 3.5 MM | 1 | |
| 7608-000 | CLAMP FOR ULNA REDUCTION GUIDE | 1 | |
| 7470-000 | ADJUSTMENT SCREW FOR ULNA REDUCTION GUIDE | 1 | |
| 7415-000 | ULNA REDUCTION GUIDE CORTICAL SCREW | 1 | |
| 7471-000 | ULNA REDUCTION GUIDE RIGHT | 1 | |
| 7472-000 | ULNA REDUCTION GUIDE LEFT | 1 | |
| 7469-000 | DRILL BIT GUIDE FOR ULNA REDUCTION GUIDE | 1 | |
| 5574-000 | SCREW FORCEPS #1 SUPPORT | 1 | |
| 5614-150 | DRILL BIT 2.5 MM X 150 MM | 2 | |
| 5615-150 | DRILL BIT 3.0 MM X 150 MM | 2 | |
| 5616-150 | DRILL BIT 3.5 MM X 150 MM | 2 | |
| 0336-100 | KIRSCHNER NAIL 2.0 MM X 100 MM, STAINLESS STEEL | 4 | |
| PM 2022-08 / 2022-47 / 2022-53 | |||
