The Rhino Knee System® is designed to more faithfully reproduce the joint’s natural movement, offering increased patient comfort, improved flexion stability, and greater implant longevity. Its anatomical design and ergonomic instrumentation provide operating-room efficiency and intraoperative flexibility. It is compatible with PS (posterior-stabilized) and CR (cruciate-retaining) tibial inserts, and includes solutions that reduce stress on soft tissues and decrease implant wear under high-flexion conditions.
Osteoarthritis.
Rheumatoid arthritis.
Post-traumatic arthropathy.
Degenerative osteoarthritis.
Knee arthropathy.
The constant-radius design favors a smooth transition during flexion, providing a more natural sensation to the patient and allowing excellent range of motion.
They increase the contact surface during deep flexion, improving posterior stability and reducing the risk of soft tissue impingement.
Precise fit between components reduces friction points and enhances implant durability.
The anatomic geometry distributes loads efficiently across the entire contact surface, contributing to greater bone protection and improved implant integration.
Offers multiple intraoperative options with a single instrument set, allowing adaptation to different anatomies and surgical philosophies without the need to change trays.
Wide range of femoral and tibial sizes, with precise adjustments to achieve appropriate ligament balance and personalization according to the patient's profile.
Designed in collaboration with surgeons, it ensures comfortable, intuitive, and precise handling, reducing operator fatigue and surgical times.
Finish that minimizes reflections under surgical lighting, improving intraoperative visibility and the surgical team's concentration.
Enables faster operating room setup and an orderly execution of the procedure, optimizing timing and reducing errors.
Deep trochlea aligned with the natural axis of the patellar tendon, facilitating a more physiologic patellar tracking and reducing anterior knee pain.
The same system allows the use of posterior-stabilized or cruciate-retaining inserts, adapting to the status of the LCP and surgical preferences.
Its design reduces improper contact in extreme flexion, minimizing the risk of insert fracture and prolonging implant lifespan.
Speak with our specialists, receive personalized assistance, and optimize your experience in the operating room with a solution designed for precision and confidence.
| Rhino® Knee Primary System / KRP-00-PRIA-X-B - KRP-00-PRIB-X-B | ||
|---|---|---|
| IMPLANTS | ||
| SYSTEM CODE | KRP-00-PRIA-X-B | |
| SYSTEM DESCRIPTION | PRIMARY IMPLANTS FOR RIGHT KNEE PROSTHESIS (A) | |
| REF. | DESCRIPTION | QTY |
| 4100-000 | RIGHT PRIMARY FEMORAL COMPONENT #1 | 1 |
| 4101-000 | RIGHT PRIMARY FEMORAL COMPONENT #2 | 1 |
| 4102-000 | RIGHT PRIMARY FEMORAL COMPONENT #3 | 1 |
| 4103-000 | RIGHT PRIMARY FEMORAL COMPONENT #4 | 1 |
| 4104-000 | RIGHT PRIMARY FEMORAL COMPONENT #5 | 1 |
| 4105-000 | RIGHT PRIMARY FEMORAL COMPONENT #6 | 1 |
| 4106-000 | RIGTH PRIMARY FEMORAL COMPONENT #7 | 1 |
| 4107-000 | RIGHT PRIMARY FEMORAL COMPONENT #8 | 1 |
| 4116-000 | PRIMARY TIBIAL COMPONENT #1 | 1 |
| 4117-000 | PRIMARY TIBIAL COMPONENT #2 | 1 |
| 4118-000 | PRIMARY TIBIAL COMPONENT #3 | 1 |
| 4119-000 | PRIMARY TIBIAL COMPONENT #4 | 1 |
| 4124-000 | UHMWPE PRIMARY TIBIAL INSERT #1 X 10 MM | 1 |
| 4125-000 | UHMWPE PRIMARY TIBIAL INSERT #1 X 12 MM | 1 |
| 4126-000 | UHMWPE PRIMARY TIBIAL INSERT #1 X 14 MM | 1 |
| 4127-000 | UHMWPE PRIMARY TIBIAL INSERT #1 X 16 MM | 1 |
| 4128-000 | UHMWPE PRIMARY TIBIAL INSERT #1 X 18 MM | 1 |
| 4129-000 | UHMWPE PRIMARY TIBIAL INSERT #2 #3 #4 X 10 MM | 1 |
| 4130-000 | UHMWPE PRIMARY TIBIAL INSERT #2 #3 #4 X 12 MM | 1 |
| 4131-000 | UHMWPE PRIMARY TIBIAL INSERT #2 #3 #4 X 14 MM | 1 |
| 4132-000 | UHMWPE PRIMARY TIBIAL INSERT #2 #3 #4 X 16 MM | 1 |
| 4133-000 | UHMWPE PRIMARY TIBIAL INSERT #2 #3 #4 X 18 MM | 1 |
| 4144-000 | UHMWPE PATELLAR COMPONENT #8 X 26 MM | 1 |
| 4145-000 | UHMWPE PATELLAR COMPONENT #8 X 28 MM | 1 |
| 4146-000 | UHMWPE PATELLAR COMPONENT #8 X 30 MM | 1 |
| 4147-000 | UHMWPE PATELLAR COMPONENT #8 X 32 MM | 1 |
| 4615-000 | UHMWPE PATELLAR COMPONENT #10 X 26 MM | 1 |
| 4616-000 | UHMWPE PATELLAR COMPONENT #10 X 28 MM | 1 |
| 4982-000 | RHINO PRIMARY PROSTHESIS TEMPLATE KIT | 1 |
| SYSTEM CODE | KRP-00-PRIB-X-B | |
| SYSTEM DESCRIPTION | PRIMARY IMPLANTS FOR RIGHT KNEE PROSTHESIS (B) | |
| REF. | DESCRIPTION | QTY |
| 4108-000 | LEFT PRIMARY FEMORAL COMPONENT #1 | 1 |
| 4109-000 | LEFT PRIMARY FEMORAL COMPONENT #2 | 1 |
| 4110-000 | LEFT PRIMARY FEMORAL COMPONENT #3 | 1 |
| 4111-000 | LEFT PRIMARY FEMORAL COMPONENT #4 | 1 |
| 4112-000 | LEFT PRIMARY FEMORAL COMPONENT #5 | 1 |
| 4113-000 | LEFT PRIMARY FEMORAL COMPONENT #6 | 1 |
| 4114-000 | LEFT PRIMARY FEMORAL COMPONENT #7 | 1 |
| 4115-000 | LEFT PRIMARY FEMORAL COMPONENT #8 | 1 |
| 4120-000 | PRIMARY TIBIAL COMPONENT #5 | 1 |
| 4121-000 | PRIMARY TIBIAL COMPONENT #6 | 1 |
| 4122-000 | PRIMARY TIBIAL COMPONENT #7 | 1 |
| 4123-000 | PRIMARY TIBIAL COMPONENT #8 | 1 |
| 4134-000 | UHMWPE PRIMARY TIBIAL INSERT #5 #6 X 10 MM | 1 |
| 4135-000 | UHMWPE PRIMARY TIBIAL INSERT #5 #6 X 12 MM | 1 |
| 4136-000 | UHMWPE PRIMARY TIBIAL INSERT #5 #6 X 14 MM | 1 |
| 4137-000 | UHMWPE PRIMARY TIBIAL INSERT #5 #6 X 16 MM | 1 |
| 4138-000 | UHMWPE PRIMARY TIBIAL INSERT #5 #6 X 18 MM | 1 |
| 4139-000 | UHMWPE PRIMARY TIBIAL INSERT #7 #8 X 10 MM | 1 |
| 4140-000 | UHMWPE PRIMARY TIBIAL INSERT #7 #8 X 12 MM | 1 |
| 4141-000 | UHMWPE PRIMARY TIBIAL INSERT #7 #8 X 14 MM | 1 |
| 4142-000 | UHMWPE PRIMARY TIBIAL INSERT #7 #8 X 16 MM | 1 |
| 4143-000 | UHMWPE PRIMARY TIBIAL INSERT #7 #8 X 18 MM | 1 |
| 4617-000 | UHMWPE PATELLAR COMPONENT #10 X 30 MM | 1 |
| 4618-000 | UHMWPE PATELLAR COMPONENT #10 X 32 MM | 1 |
| 4619-000 | UHMWPE PATELLAR COMPONENT #12 X 26 MM | 1 |
| 4620-000 | UHMWPE PATELLAR COMPONENT #12 X 28 MM | 1 |
| 4621-000 | UHMWPE PATELLAR COMPONENT #12 X 30 MM | 1 |
| 4622-000 | UHMWPE PATELLAR COMPONENT #12 X 32 MM | 1 |
| ASSOCIATED INSTRUMENTS | ||
| SYSTEM CODE | KRP-00-PRI1-X-T | |
| SYSTEM DESCRIPTION | PRIMARY INSTRUMENTS FOR KNEE PROSTHESIS 1 | |
| REF. | DESCRIPTION | QTY |
| 4301-000 | FEMORAL MEDULLARY GUIDE | 1 |
| 4395-020 | FEMORAL CONDYLE HOLDER | 1 |
| 4345-000 | REAMER CAP Ø 20 mm | 1 |
| 4344-000 | REAMER Ø20 MM | 1 |
| 4343-000 | TIBIAL REAMER GUIDE | 1 |
| 4312-000 | TIBIAL SPACER #10 | 1 |
| 4313-000 | TIBIAL SPACER #12 | 1 |
| 4314-000 | TIBIAL SPACER #14 | 1 |
| 4315-000 | TIBIAL SPACER #16 | 1 |
| 4316-000 | TIBIAL SPACER #18 | 1 |
| 4333-000 | TIBIAL TRIAL IMPLANT, #1 | 1 |
| 4334-000 | TIBIAL TRIAL IMPLANT, #2 | 1 |
| 4335-000 | TIBIAL TRIAL IMPLANT, #3 | 1 |
| 4336-000 | TIBIAL TRIAL IMPLANT, #4 | 1 |
| 4337-000 | TIBIAL TRIAL IMPLANT, #5 | 1 |
| 4338-000 | TIBIAL TRIAL IMPLANT, #6 | 1 |
| 4339-000 | TIBIAL TRIAL IMPLANT, #7 | 1 |
| 4340-000 | TIBIAL TRIAL IMPLANT, #8 | 1 |
| 4303-000 | IMPACTOR | 1 |
| 4346-020 | TIBIAL IMPLANT IMPACTOR | 1 |
| 4411-020 | TRIAL INSERT IMPACTOR | 1 |
| 4302-000 | ROD FOR MEDULLARY GUIDE x 163 mm | 1 |
| 4406-020 | FEMORAL DRILL BIT GUIDE | 1 |
| 4311-020 | FEMORAL IMPACTOR | 1 |
| 4417-000 | DRILL BIT Ø 8 MM | 1 |
| 4660-000 | HANDLE FOR SINGLE PREPARATION GUIDE | 1 |
| 4342-020 | HANDLE FOR TIBIAL RASP | 1 |
| 4392-000 | OSTEOTOME BLADE 50 mm | 1 |
| 4661-000 | OSTEOTOME BLADE 55 mm | 1 |
| 4662-000 | OSTEOTOME BLADE 60 mm | 1 |
| 4656-000 | ROD FOR MEDULLARY GUIDE x 235 mm | 1 |
| 4657-000 | ROD FOR MEDULLARY GUIDE x 300 mm | 1 |
| SYSTEM CODE | KRP-00-PRI2-X-T | |
| SYSTEM DESCRIPTION | PRIMARY INSTRUMENTS FOR KNEE PROSTHESIS 2 | |
| REF. | DESCRIPTION | QTY |
| 4410-000 | RASP | 1 |
| 4398-000 | CUTTING GAUGE, LARGE | 1 |
| 4666-000 | CUTTING GAUGE, SMALL | 1 |
| 4396-000 | TRIAL INSERT REMOVER | 1 |
| 4407-000 | SINGLE LEVER | 2 |
| 4668-000 | DOUBLE LEVER | 2 |
| 4408-000 | PLIER | 1 |
| 4413-000 | ADAPTER | 1 |
| 4412-000 | CURVED OSTEOTOME | 1 |
| 4383-000 | HANDLE FOR DOUBLE PREPARATION GUIDES | 1 |
| 4425-000 | POSTERIOR STABILITY ACCESSORY #45 | 1 |
| 4426-000 | POSTERIOR STABILITY ACCESSORY #50 | 1 |
| 4427-000 | POSTERIOR STABILITY ACCESSORY #54 | 1 |
| 4421-000 | PATELLAR TRIAL IMPLANT#8 X 26 MM | 1 |
| 4422-000 | PATELLAR TRIALIMPLANT #8 X 28 MM | 1 |
| 4423-000 | PATELLAR TRIAL IMPLANT #8 X 30 MM | 1 |
| 4424-000 | PATELLAR TRIAL IMPLANT#8 X 32 MM | 1 |
| 4415-000 | DRILL BIT Ø 3 MM | 2 |
| 4418-000 | DRILL BIT Ø 5 MM | 1 |
| 4416-000 | DRILL BIT Ø 6 MM | 1 |
| 4414-000 | ADAPTER SCREW | 1 |
| 4404-000 | FIXATION PIN, 56 MM | 4 |
| 4405-000 | FIXATION PIN, 76 MM | 6 |
| 4403-000 | FIXATION PIN WITH CAP, 60 MM | 4 |
| 4402-000 | FIXATION PIN WITH CAP, 40 MM | 4 |
| 4401-000 | FIXATION PIN WITH CAP, 25 MM | 4 |
| 5823-000 | SCREW FORCEPS #3 | 1 |
| 4384-000 | EXTERNAL BLOCK FOR ANTERIOR ROTATION 0° 3° LEFT | 1 |
| 4385-000 | EXTERNAL BLOCK FOR ANTERIOR ROTATION 3° 0° RIGHT | 1 |
| 4386-000 | EXTERNAL BLOCK FOR ANTERIOR ROTATION 5° 7° LEFT | 1 |
| 4387-000 | EXTERNAL BLOCK FOR ANTERIOR ROTATION 7° 5° RIGHT | 1 |
| 4388-000 | EXTERNAL BLOCK FOR POSTERIOR ROTATION 0° 3° LEFT | 1 |
| 4389-000 | EXTERNAL BLOCK FOR POSTERIOR ROTATION 3° 0° RIGHT | 1 |
| 4390-000 | EXTERNAL BLOCK FOR POSTERIOR ROTATION 5° 7° LEFT | 1 |
| 4391-000 | EXTERNAL BLOCK FOR POSTERIOR ROTATION 7° 5° RIGHT | 1 |
| 4307-000 | FEMUR SIZER #1 #2 | 1 |
| 4308-000 | FEMUR SIZER #3 #4 | 1 |
| 4309-000 | FEMUR SIZER #5 #6 | 1 |
| 4310-000 | FEMUR SIZER #7 #8 | 1 |
| 4419-000 | PATELLA GAUGE Ø BETWEEN HOLES 7 mm | 1 |
| 4669-000 | PATELLA GAUGE Ø BETWEEN HOLES 11 mm | 1 |
| 4420-000 | CLAMP FOR PATELLAR COMPRESSION | 1 |
| 4341-000 | TIBIAL RASP, WINGED, 20 MM WIDE | 1 |
| 4658-000 | TIBIAL RASP, WINGED, 23 MM WIDE | 1 |
| 4659-000 | TIBIAL RASP, WINGED, 26 MM WIDE | 1 |
| 6201-020 | MALLET #2 | 1 |
| 4399-000 | HANDLE FOR TRIAL TESTER | 1 |
| 4304-000 | DISTAL GUIDE FOR FEMORAL CUTTING | 1 |
| 4409-000 | PATELLAR CALIPER | 1 |
| 4099-000 | CUTTING BLOCK FOR A PATELLAR COMPRESSION CLAMP | 1 |
| SYSTEM CODE | KRP-00-PRI3-X-T | |
| SYSTEM DESCRIPTION | PRIMARY INSTRUMENTS FOR KNEE PROSTHESIS 3 | |
| REF. | DESCRIPTION | QTY |
| 4400-000 | ALIGNMENT ROD WITH FITTING | 1 |
| 4667-000 | ALIGNMENT ROD W/O FITTING | 1 |
| 4633-000 | CR TIBIAL TRIAL INSERT #5 #6 X 10 MM | 1 |
| 4634-000 | CR TIBIAL TRIAL INSERT #5 #6 X 12 MM | 1 |
| 4635-000 | CR TIBIAL TRIAL INSERT #5 #6 X 14 MM | 1 |
| 4636-000 | CR TIBIAL TRIAL INSERT #5 #6 X 16 MM | 1 |
| 4637-000 | CR TIBIAL TRIAL INSERT #5 #6 X 18 MM | 1 |
| 4638-000 | CR TIBIAL TRIAL INSERT #7 #8 X 10 MM | 1 |
| 4639-000 | CR TIBIAL TRIAL INSERT #7 #8 X 12 MM | 1 |
| 4640-000 | CR TIBIAL TRIAL INSERT #7 #8 X 14 MM | 1 |
| 4641-000 | CR TIBIAL TRIAL INSERT #7 #8 X 16 MM | 1 |
| 4642-000 | CR TIBIAL TRIAL INSERT #7 #8 X 18 MM | 1 |
| 4397-000 | ANKLE FIXATOR | 1 |
| 4306-000 | EXTERNAL POSITIONER FOR TIBIAL ROD | 1 |
| 4300-000 | ALIGNMENT ROD CONNECTOR | 1 |
| 4394-000 | TIBIAL CUTTING BLOCK, LEFT | 1 |
| 4664-000 | TIBIAL CUTTING BLOCK, CENTRAL | 1 |
| 4665-000 | TIBIAL CUTTING BLOCK, RIGHT | 1 |
| 4305-000 | TIBIAL CUTTING GUIDE | 1 |
| 4347-000 | TIBIAL TRIAL INSERT #1 X 10 MM | 1 |
| 4348-000 | TIBIAL TRIAL INSERT #1 X 12 MM | 1 |
| 4349-000 | TIBIAL TRIAL INSERT #1 X 14 MM | 1 |
| 4350-000 | TIBIAL TRIAL INSERT #1 X 16 MM | 1 |
| 4351-000 | TIBIAL TRIAL INSERT #1 X 18 MM | 1 |
| 4352-000 | TIBIAL TRIAL INSERT #2 #3 #4 X 10 MM | 1 |
| 4353-000 | TRIAL TIBIAL INSERT #2 #3 #4 X 12 MM | 1 |
| 4354-000 | TRIAL TIBIAL INSERT #2 #3 #4 X 14 MM | 1 |
| 4355-000 | TIBIAL TRIAL INSERT #2 #3 #4 X 16 MM | 1 |
| 4356-000 | TIBIAL TRIAL INSERT #2 #3 #4 X 18 MM | 1 |
| 4357-000 | TIBIAL TRIAL INSERT #5 #6 X 10 MM | 1 |
| 4358-000 | TIBIAL TRIAL INSERT#5 #6 X 12 MM | 1 |
| 4359-000 | TIBIAL TRIAL INSERT #5 #6 X 14 MM | 1 |
| 4360-000 | TIBIAL TRIAL INSERT #5 #6 X 16 MM | 1 |
| 4361-000 | TIBIAL TRIAL INSERT #5 #6 X 18 MM | 1 |
| 4362-000 | TIBIAL TRIAL INSERT #7 #8 X 10 MM | 1 |
| 4363-000 | TIBIAL TRIAL INSERT #7 #8 X 12 MM | 1 |
| 4364-000 | TIBIAL TRIAL INSERT #7 #8 X 14 MM | 1 |
| 4365-000 | TIBIAL TRIAL INSERT #7 #8 X 16 MM | 1 |
| 4366-000 | TIBIAL TRIAL INSERT #7 #8 X 18 MM | 1 |
| 4623-000 | CR TIBIAL TRIAL INSERT #1 X 10 MM | 1 |
| 4624-000 | CR TIBIAL TRIAL INSERT #1 X 12 MM | 1 |
| 4625-000 | CR TIBIAL TRIAL INSERT #1 X 14 MM | 1 |
| 4626-000 | CR TIBIAL TRIAL INSERT #1 X 16 MM | 1 |
| 4627-000 | CR TIBIAL TRIAL INSERT #1 X 18 MM | 1 |
| 4628-000 | CR TIBIAL TRIAL INSERT #2 #3 #4 X 10 MM | 1 |
| 4629-000 | CR TIBIAL TRIAL INSERT #2 #3 #4 X 12 MM | 1 |
| 4630-000 | CR TIBIAL TRIAL INSERT #2 #3 #4 X 14 MM | 1 |
| 4631-000 | CR TIBIAL TRIAL INSERT #2 #3 #4 X 16 MM | 1 |
| 4632-000 | CR TIBIAL TRIAL INSERT #2 #3 #4 X 18 MM | 1 |
| SYSTEM CODE | KRP-00-PRI4-X-T | |
| SYSTEM DESCRIPTION | PRIMARY INSTRUMENTS FOR KNEE PROSTHESIS 4 | |
| REF. | DESCRIPTION | QTY |
| 4317-000 | FEMORAL TRIAL IMPLANT, LEFT, #1 | 1 |
| 4318-000 | FEMORAL TRIAL IMPLANT, LEFT, #2 | 1 |
| 4319-000 | FEMORAL TRIAL IMPLANT, LEFT, #3 | 1 |
| 4320-000 | FEMORAL TRIAL IMPLANT, LEFT, #4 | 1 |
| 4321-000 | FEMORAL TRIAL IMPLANT, LEFT, #5 | 1 |
| 4322-000 | FEMORAL TRIAL IMPLANT, LEFT, #6 | 1 |
| 4323-000 | FEMORAL TRIAL IMPLANT, LEFT, #7 | 1 |
| 4324-000 | FEMORAL TRIAL IMPLANT, LEFT, #8 | 1 |
| 4325-000 | FEMORAL TRIAL IMPLANT, RIGHT, #1 | 1 |
| 4326-000 | FEMORAL TRIAL IMPLANT, RIGHT, #2 | 1 |
| 4327-000 | FEMORAL TRIAL IMPLANT, RIGHT, #3 | 1 |
| 4328-000 | FEMORAL TRIAL IMPLANT, RIGHT, #4 | 1 |
| 4329-000 | FEMORAL TRIAL IMPLANT, RIGHT, #5 | 1 |
| 4330-000 | FEMORAL TRIAL IMPLANT, RIGHT, #6 | 1 |
| 4331-000 | FEMORAL TRIAL IMPLANT, RIGHT, #7 | 1 |
| 4332-000 | FEMORAL TRIAL IMPLANT, RIGHT, #8 | 1 |
| 4367-000 | FEMORAL CUTTING BLOCK #1 | 1 |
| 4368-000 | FEMORAL CUTTING BLOCK #2 | 1 |
| 4369-000 | FEMORAL CUTTING BLOCK #3 | 1 |
| 4370-000 | FEMORAL CUTTING BLOCK #4 | 1 |
| 4371-000 | FEMORAL CUTTING BLOCK #5 | 1 |
| 4372-000 | FEMORAL CUTTING BLOCK #6 | 1 |
| 4373-000 | FEMORAL CUTTING BLOCK #7 | 1 |
| 4374-000 | FEMORAL CUTTING BLOCK #8 | 1 |
| 4393-000 | OSTEOTOME IMPACTOR 43mm WIDE | 1 |
| 4663-000 | OSTEOTOME IMPACTOR 60 mm WIDE | 1 |
| 4375-000 | FEMORAL PREPARATION GUIDE #1 | 1 |
| 4376-000 | FEMORAL PREPARATION GUIDE #2 | 1 |
| 4377-000 | FEMORAL PREPARATION GUIDE #3 | 1 |
| 4378-000 | FEMORAL PREPARATION GUIDE #4 | 1 |
| 4379-000 | FEMORAL PREPARATION GUIDE #5 | 1 |
| 4380-000 | FEMORAL PREPARATION GUIDE #6 | 1 |
| 4381-000 | FEMORAL PREPARATION GUIDE #7 | 1 |
| 4382-000 | FEMORAL PREPARATION GUIDE #8 | 1 |
| PM 2022-18 / 2022-53 / 2022-112 | ||
